V-PORT BALL VALVE (VTMV1/VTMV2)
 STANDARD COMPLIANCE
Content Standard
    Design and Manufacturing Standard API6D/BS5351/ASME B16.34
    Face to Face Dimensions ASME B6.10
    Flanged Type and Dimensions ASME B16.5
    Butt-Welded Ends ASME B16.25
    Inspection and Test API6D/API598
    Size Range 2"~12"
    Pressure Range 150 Lb~600 Lb

SBV V-Port Ball Valve is applicable for the fluid containing fibers, the high-viscosity fluid containing solid particles, the special fluid control and flow regulating, it can also be used as the isolating valve for its reliable sealing. It is widely employed in chemical industry, paper-making, petroleum, electric power, etc. It has excellent performance.

1. Good Performance of Flow Adjustment Control
The ball is of "V" type pattern. At any position from full open to full close, it always keeps the standard geometry. The large adjustable extent is from 100:1 to 200:1,the CV curve of discharge characteristic is similar to the percentage curve, which may realize the precise control of the flow.

2. One Piece or Two Piece Body
The strength of body is high, stress deformation resistance is strong, confinement reliability is improved, has no bending transition at the flow passage, not accumulate, not block, has little influence upon the fluid.

3. Reliable Seat Sealing
The sealing surface build-up welding is handled by hard facing and employ the advanced seat grinding technology and gridding ball technology to make V type ball valve have reliable sealing performance which can achieve the V sealing grade of ANSI B16.104 specified. The special requirement can achieve VI grade.

4. Ball
The ball hard surface handled by STL, tungsten, etc. Both the two ends are V pattern, which is easy to precise control for flow also can realize the shearing action for the fluid containing cellulosic, the high-viscosity fluid containing solid particles when shutting.

5. Sealing Packing
The stem adopts the adjustable jam type packing of V type PTFE or RPPL. Ensure that has reliable sealing and no out leakage under the middle and high temperature.

6. Operation Type and & Positioner
SBV "V" Type Ball Valve complement using driver adopts the adjustable manual exerciser, pneumatic driver(with positioner) and adjustable electric driver.
